Stainless Steel 42000 Litres Tank Semi Trailer Diesel Jet Fuel Truck 20 - 100T Loading Capacity

Name: Stainless Steel 42000 Litres Tank Semi Trailer Diesel Jet Fuel Truck 20 100T Loading Capacity
Brand: HUATE
Price: 9 USD

Place of Origin : Hubei, China

Brand Name : HUATE

Price : $9,000/sets 1-9 sets

Use : Truck Trailer

Type : Semi-Trailer

Material : Stainless Steel 5182, Stainless Steel 5182

Size : 10370*2500*3800(mm), 10370*2500*3800(mm)

Max Payload : 25001-30000 kg

Product name : Fuel Tank Trailer

Storage : Fuel ,Such as: Gasoline, Kerosene, Diesel and Jet fuel

Axle : 2/3/4 Axle

Tire Specification : 11.00R20 12PR 12R22.5 12PR

Color : Customer's Request

Loading capacity : 20-100T

MOQ : 1

Packaging Details : Wooden box

Delivery Time : 7-30 days

Payment Terms : T/T

Supply Ability : Meet large-scale orders

Contact Now

Products Description

Customized Oil Transport Tank Semi Trailer Fuel Delivery Tankers for Sale Large Capacity Oil Tank Trailer Tanker trailer is also known as tanker, highway tanker, etc. It is mainly used for transportation and storage of oil products suchas petroleum derivatives, gasoline, diesel, crude oil, lubricating oil and coal tar. Tanker trailers are widely used in oil
depots, gas stations, oil fields, chemical plants, food plants, asphalt plants, etc.
The tank body of fuel tanker trailer can be made of different materials such as aluminum, carbon steel, and stainless steel.
The tank is built with multi-channel reinforced anti wave baffle plate, and the lower end of the baffle plate is designed with
through holes to reduce the impact of fuel in the tank and improve the strength of the tank.
The combined tank opening is located at the top of the tank body. A self-locking small cover is arranged on the large cover, and a breathing valve is installed on top of the large cover to ensure the consistency of atmospheric pressure inside and outside the tank. There is also the electrostatic grounding wire. Installed fuel pump system allows the fuel tanker trailer to self-prime and self-drain. Two separate pumping pipes are included along with a suction lift, two fire extinguishers, and too

Product Name	Fuel Transport Tank Semi Trailer
Overall dimensions	10400×2500×3800(mm)
GVW	35000Kg
Total net weight	5200Kg
Loading capacity	29800Kg
Tank capacity( CBM )	30000L to 60000L
Medium	Fuel Such As: Gasoline, Kerosene, Diesel and Jet Fuel
Tank body thickness(mm)	Stainless Steel 5182 5mm steel
End plate	Stainless Steel 5182 6mm steel
Compartment	2-6 As Customer Need
Chassis brand	HUATE
Approach/departure angle	/19°
Tire specification	11.00R20 12PR,12R22.5 12PR
Transmission	Manual
Axle Number	2
Axle Brand	BPW/FUWA/ZY/ L1/HO’S/ SAF/ PDME,13ton Axle
Manhole covers	500mm manhole cover .3 sets with 3 breather valve.
Discharge Valve	4’change into 3’
Dischage Pipe	4’seamless steel tube
Discharge Valve Vox	Totally-enclosed
Spill Discharges	1at the rear
Bottom Valve	1 Set
Rear Ladder	Dismountable
Walkway	On the top
Top Ladder	Standard
Pedal	Anti-Skid Pedal
Color and Logo	As Customer Need
Standard Configuration	Chassis,Arc-shaped Body,Sub Frame,Rear Lifting Part,Loading Bunker,Pushing-out Plate,Sewage Tank,Climbing Ladder
Selective Configuration	Multifunctional Rear Lifting Part,Rear Handrail and Footplate,Other shapes of body etc.
